Miele CM6 - Operation Tests; Sensor and Display Testing

Technical Information
40
CM6
Function Options Description
Component (press
OK to start or stop
activation)
R39 (cup warmer)
(CM 63x0 only)
Activate: Press O
K
.
Deactivate: Press OK again.
Sensor value
R30-14 (heater NTC) Heater temperature
is displayed
B3-4 (flow meter) Flow meter pulses per second
is displayed.
Switch status
S87-1 (drip tray present switch) 0 = Drip tray not inserted
1 = Drip tray inserted
B3-18 (water tank sensor) 0 = Not inserted or inserted but
empty
1 = Inserted and full
S60-1 / S60-2 (brew unit position switches) Move the brew unit to the
corresponding position and
compare with Table 001-6.
S87-2 (brew unit present switch) 0 = Brew unit inserted and
locked
1 = Brew unit not inserted or
brew unit inserted but not
locked
S51-4 (grind amount step contact switch) 0 = Activated
1 = Not activated
S87-5 (chute present switch) 0 = Chute closed
1 = Chute open
S51-1 (ceramic valve step contact switch) 0 = Activated
1 = Not activated
S60-3 (ceramic valve position switch) 0 = Activated
1 = Not activated
S87-6 (spout present switch) 0 = Not inserted
1 = Inserted
Total operating
hours
Total operating hours are displayed.
Operation
Display The display and the drink
touchpads light up.
Press O
K
to start/stop
test
Display backlight The display text lights up.
Buzzer Buzzer sounds
continuously.
Press O
K
to stop test
(Touch-) sensors
(press the
touchpad to be
tested; the
number of the
touchpad sensor
is displayed)
Sensor 102 pressed
Sensor 103 pressed
Sensor 107 pressed
Sensor 108 pressed
Sensor 65 pressed
Sensor 26 pressed
Sensor 66 pressed
Sensor 16 pressed (press
only briefly)
Sensor 82 pressed (CM
63x0 only)
Sensor 69 pressed
Sensor 68 pressed (CM
63x0 only)
