Miele CVA615 - Interference Suppression Filter - Removal; Rear Panel - Removal

Technical Information
42
CVA615 Coffee System
5.2 Interference Suppression Filter (Z1) - Removal
1. Perform: Lid removal (5.1).
2. Remove the Mains Filter Nut (Figure 5-2 - Item 1).
3. Remove the Filter.
4. Disconnect the Mains Filter electrical connections
Figure 5-2: Interference Suppression Filter (Z1) Mounting Location
5.3 Rear Panel - Removal
1. Remove the lid (5.1).
2. Remove the Mains Filter (5.2).
3. Remove the fixing screws from the rear panel.
4. Disconnect the ground connection from the rear panel.
5. Remove the Rear Panel upwards.
Figure 5-3: Rear Panel Removal
