Miele CVA615 - Overflow Switch Actuator Float - Removal

Technical Information
47
CVA615 Coffee System
5.8 Overflow Switch Actuator Float - Removal
1. Remove the Lid, Mains and Rear Panel (5.1 to 5.3)
2. Remove the Base Plate (5.6)
Note
Ensure the float in re-installed in the same direction, as when it
was removed.
3. Remove the Float.
Figure 5-8: (1) Overflow Switch Float. (2) Magnet inside of the float.
