Technical Information
88
CVA615 Coffee System
5.41 Dispensing Solenoid - Removal
1. Remove the Top Lid (5.1).
2. Remove the Rear Panel (5.3).
3. Remove the Beans Container (5.39).
4. Remove the Beans Container Guide (5.40).
5. Press the retainers outward.
6. Slide the Dispensing Solenoid upward out of the guide.
7. Disconnect the electrical connections.
5.42 Dispenser Switch - Removal
1. Remove the Top Lid (5.1).
2. Remove the Rear Panel (5.3).
3. Remove the Beans Container (5.39).
4. Remove the Beans Container Guide (5.40).
5. Remove the Dispensing Solenoid (5.43)
6. Press the retainers outwards. Remove the switch.
7. Disconnect the electrical connections.
