Technical Information
54
CVA615 Coffee System
5.15 Coffee Dispensing Nozzle - Installation
Refer to figure 5-14.
1. Slide the outlet (7), onto the connection hose (6).
2. Position the moveable coffee dispensing nozzle, (9), in the
cover (10).
3. Clip the outlet (7), in the cover (10).
Note
The two screws for the coffee dispensing nozzle should be
tightened by hand only as they can easily be over tightened.
4. Fit the Coffee Dispensing Nozzle in the frame.
5. Install the white panel and screws.
