Miele CVA615 - Adjustment Slide Switch Frame - Removal

Technical Information
43
CVA615 Coffee System
5.4 Adjustment Slide Switch Frame - Removal
1. Open the door.
2. Pull off the slide switch knobs.
3. Press the retaining lugs inwards with a small screwdriver
(Figure 5-4).
4. Remove the frame.
Figure 5-4: Removing the Adjustment Slide Switch Frame (Bezel).
