Miele CVA615 - 5.32 Brew Unit Drives - Service

Technical Information
71
CVA615 Coffee System
5.32 Brew Unit Drives – Service
1. Disconnect the power. Allow the appliance to cool.
2. Remove the Brew Unit from the appliance (5.20 or 5.21)
3. Remove the Waste Container from the appliance.
4. Remove the Beans Container (5.38) and Beans Container
Guide (5.39)
5. Remove the Lid (5.1)
6. Remove the Rear Panel (5.3)
Important
Before unplugging any connections, label the plugs and connectors
to ensure the wiring is returned to the correct locations during re-
assembly.
7. Disconnect L1 and N from the Door Switch to the Interference
Suppressor
8. Disconnect the ground wires from the Cord Socket / Terminal
Block.
9. Disconnect the following connections from the Power Electronic:
 JP2
 JP12
 JP4
10. Disconnect the following connections from the CPU Electronic:
 JP34
 JP35
 JP25
 JP39
 JP41 (Ribbon Cable)
11. Disconnect the ground connection from the Dispenser Solenoid.
12. Disconnect the ground connection from the Hot Water Heater.
13. Remove the CPU Electronic (with its mounting assembly) and
position toward the rear outside of the appliance.
14. Remove the Steam Heater from its mount and position it outside
the appliance.
