Miele CVA615 - 5.26 Brew Unit - Lubrication

Technical Information
65
CVA615 Coffee System
5.26 Brew Unit – Lubrication
1. Remove the Brew Unit.
Note
Check that the Brew Unit is in the basic position with the funnel
slightly lifted and the socket in vertical position.
2. Refer to figure 5-22; lubricate the following:
A: Joints
B: Axel
C: Tracks
D: Gasket
Figure 5-22: Brew Unit lubrication points
3. Refer to figure 5-23; lubricate the following:
E: Bolt Assembly
F: Joints
Figure 5-23: Brew Unit lubrication points
4. Return the brew unit into the appliance.
