Miele CVA615 - 5.21 Brew Unit - Removal ( NOT in start;home position)

Technical Information
59
CVA615 Coffee System
5.21 Brew Unit — Removal ( NOT
in start/home position)
Warning
This procedure will remove the brew unit from the appliance without
damages. However.., after the brew unit is removed; the drives
must be carefully inspected (and repaired if necessary) then placed
into the start (home) position via the service mode.
Before proceeding close the front door, turn the power on to initiate
a drive reset during the start-up sequence.
Once “Ready...” is displayed; open the front door and attempt to
remove the brew unit. If the brew unit still cannot be easily
removed, perform the following:
Refer to figures 5-17 and 5-18 on the next page…
1. Open front door - Remove the Waste Container.
2. Locate the Philips screw (Figure 5-17, Item 2).
3. Remove the Philips screw.
4. Use a small flat tip screwdriver to left up on the locking tab
(Figure 5-18).
5. Grasp the brew unit handle and pull the brew unit out till the
connection socket on the brew unit (Figure 5-17, Item 1)
unsnaps from the brew unit and remains inside the appliance
attached to the water nozzle.
6. Remove the Brew Unit.
7. Slide the connection down to remove it from the appliance.
8. Re-install the connection socket to the Brew Unit.
9. Carefully inspect the drives for defects.
10. Test the Home Position Switch and Brewing Position Switch for
proper operation.
