Miele CVA615 - Overflow Switch - Removal

Technical Information
48
CVA615 Coffee System
5.9 Overflow Switch (B8/3) - Removal
1. Remove the Lid, Mains and Rear Panel (5.1 to 5.3)
2. Remove the Overflow Switch Fixing Screw (1).
3. Remove the Overflow Switch.
4. Disconnect the Overflow Switch connections from the
Electronic.
Figure 5-9: Overflow Switch
