Miele CVA615 - Page 87

Technical Information
79
CVA615 Coffee System
5. Remove the Bottom Plate and Drip Tray (5.6 & 5.7)
6. Disconnect the lower part of the valve connections,
7. Remove the lower part of the valve.
Fig. 5-41: Underside view of the CVA615 with Base Plate and
Drip Tray removed.
