Technical Information
83
CVA615 Coffee System
9. Turn the Adjustment Ring (Figure 5-45, Item 1),
counterclockwise until the blue marking aligns with the blue
marking on the carrier (Figure 5-45, Item 2).
Figure 5-45: Grinder; (1) Adjustment Ring (2) Carrier (3) Bracket.
10. Remove the bracket (Figure 5-45, Item 3)
11. Remove coffee residues, e.g. with a vacuum cleaner.
Note
The Grinding Cone Fixing Screw has a left-hand thread.
12. Remove the grinding cone fixing screw (Figure 5-46, Item 1) by
turning it clockwise.
13. Remove the intake worm gear (Figure 5-46, Item 2).
14. Remove the washer (Figure 46, Item 3).
