Novotronic Models
Technical Information
42
Shelf Runner - Removal (continued)
3. Remove the shelf runner
Figure 5-16: Removing the Shelf Runner
5.18 Reflector and Glass Cover - Removal
1. Perform door removal procedure
2. Perform oven removal
3. Perform front cover removal
4. Perform rear cover removal
5. Perform left or right side paned removal
6. Perform left or right shelf runner removal
7. Press in the retaining springs and push them into the cabinet
8. Remove the reflector upwards and disconnect the electrical
connections
9. Remove the glass cover from the interior of the cabinet
Figure 5-17: Reflector and Electrical Connection
