Novotronic Models
Technical Information
52
5.34 Temperature Regulator - Removal
(Pyrolytic/Self-Cleaning Models)
1. Perform door removal procedure
2. Perform oven removal
3. Perform front cover removal
4. Perform rear panel removal
5. Disconnect the pyrolitic temperature regulator connections
6. Remove the pyrolitic temperature regulator retaining screws
7. Remove the pyrolitic temperature regulator
Figure 5-24: Temperature Regulators
Warning
When installing, the temperature regulator sensor must rest on the oven
cavity. The sensor must not be inserted in the insulation
