Novotronic Models
Technical Information
39
5.12 Left Or Right Door Hinge Bearing - Removal
1. Perform door removal procedure
2. Perform oven removal
3. Perform front cover removal
4. Perform rear cover removal
5. Perform left or right side paned removal
6. Perform left or right deflector strip removal
7. Remove the appropriate hinge bearing attachment screw
Figure 5-12: Removing the Hinge Mounting Screws
8. Remove the appropriate hinge from the rear
