Novotronic Models
Technical Information
56
Position Display Machine Response
0 --00 None
1 e.g. H 01 Programmed model
variant displayed see
Table 6-1
2 e.g. -001 Electronic version
3 --03 Vacant
4 --04 Vacant
5 --05 Vacant
6 --06 Vacant
7 --07 Vacant
8 --08 Cooling fan at baking
speed (Hi)
9 --09 Cooling fan at run-on
speed (Low)
10 --10 Convection fan at max
speed (Max)
11 --11 Convection fan at min
speed
12 --12 Oven lights on
13 88:88 Display test
14 --14 Buzzer on
15 --15 Vacant
16 e.g. 65 C –shown if roast
probe not connected
Actual temp detected by
roast probe
17 --17 Vacant
18 --18 Vacant
19 --19 Vacant
20 --20 Vacant
21 --21 Cooling fan activated at
pyrolitic cleaning speed
(since electronic version
ID 377)
22 --22 Door Lock (H387BP KAT
only)
23 FREI Vacant
24 --24 Demonstration mode
activated
25 --25 Fault Code retrieval
26 FREI Vacant
27 e.g. 0012 Operating hours for Fan
Heat and Auto Roast
1S i Md P ii (C i d Tbl 6
Table 6-2: Service Mode Positions (Continued on Table 6-2)
