TS571W Installation Instructions 9
Warning Sign
Pedestrian Gate
Pedestrian Gate Lock
(recommended, not included)
7 foot
minimum
Control Box
Vehicular Gate
Important Safety Information
Warning signs alert people of automatic gate operation and are required when installing Mighty Mule Automatic Gate Operators. A
minimum of two WARNING SIGNS must be installed in the area of the gate. Each sign is to be visible by persons located on the side
of the gate on which the placard is installed.
The operator is intended for installation only on gates used for vehicles. Pedestrians must be supplied with a separate access
opening. The pedestrian access opening shall be designed to promote pedestrian usage. Locate the gate such that persons will not
come in contact with the vehicular gate during the entire path of travel of the vehicular gate.
We recommend using the Bulldog Pedestrian Gate Lock (Call the Nortek Security & Control Sales Department at 800-543-4283) for
controlled access.
INSTALLING WARNING SIGNS AND PEDESTRIAN GATES
Warning Signs
The gate operator is provided with two safety warning signs.
The signs MUST be installed on the front and back of the gate where they will be visible in the area of
the gate.
Permanently secure each warning sign to the gate.
Immediately replace a damaged, eligible or missing warning sign.
Call Customer Service at 800-543-4283 for a free replacement.
!
Example of TS571W Installation
(Installations vary slightly on different types of gates)
