Mighty Mule TS571W - Technical Specifications; Drive Specifications; Power Requirements; Control Features

TS571W Installation Instructions 11
Technical Specications
Maximum Weight (lbs.) Maximum Length (ft.)
850 8
750 10
650 12
550 14
450 16
350 18
MIGHTY MULE TS571W GATE OPENER
NOTE: Ball bearing hinges should be used on all gates weighing over 250 lb.
The Gate Capacity Chart above shows the recommended maximum gate length to weight. The minimum recommended
gate length is 5 ft.
_____________________________________
DRIVE
_____________________________________
• Low friction screw drive (linear actuator) rated for -5 °F to +160 °F (-20 °C to +71 °C).
• Powered by a 12 V motor with integral gear reducer. Motor speed reduced to 348 rpm at 12 V.
• Maximum opening arc of 110°. Approximate opening time (90°): 18 seconds, depending on weight of gate.
_____________________________________
POWER
_____________________________________
• The system is powered by a 12 Vdc automotive, lawn, tractor or marine battery (required but not included). A second Mighty Mule battery
may be used (not included).
• Battery charger is on the control board and maintained by a 120VAC to 19VDC output transformer or by optional Solar Panels; the panel
should generate minimum of 10 Watts (600 mA/20 watt max.). A diode on the control board prevents battery discharge. IMPORTANT:
Never use both transformer and solar panel— this will damage the battery and control board.
• Three (3) Mini blade-style fuses rated for 25A.
• NOTE: The transformer should not be directly connected to any battery. Do not replace fuses with higher
ampere rated fuses; doing so will void your warranty and may damage your control board.
_____________________________________
CONTROL
_____________________________________
• Microprocessor-based control board is set for single or dual leaf, pull-to-open or push-to-open installations.
• Control board has temperature compensated circuits.
• Learn based digital transmitter technology provides millions of codes for enhanced security.
• Opener length with push-pull tube fully retracted is 40 1/4”, mounting point to mounting point. Maximum stroke is 20”.
• Adjustable auto-close timer (OFF to 3–120 seconds), and Dual Sense Technology™ stall force).
• Power terminal block accommodates a transformer or solar panels.
• Accessory terminal block fully compatible with all Mighty Mule access controls.
• Control board allows connection of edge sensors and photoelectric sensors.
• Audio entrapment alarm sounds if unit encounters an obstruction twice while opening or closing.
__________________________________
OPERATIONAL CAPACITY
_________________________________
