28 TS571W Installation Instructions
● Remove the operator from the gate post
and gate brackets.
● Swing the gate to the open position.
● With the gate fully open, install the
closed position stop plate on the gate
opposite the operator (hardware not
included).
● Do not fully tighten hardware until after
the next step.
INSTALLING THE CLOSED POSITION STOP PLATE / PUSH-TO-OPEN
1
1
2
Step 1
Step 2
● Swing the gate to the closed position,
and adjust the closed position stop plate
against the fence post.
● Tighten the mounting hardware.
● With the gate in the closed position,
reinstall the operator arm.
