Mighty Mule TS571W - Items Included for Installation

14 TS571W Installation Instructions
Control Box, Antenna
& Battery Harness
Operator
Arm
Gate Bracket
Post Pivot Bracket
Post Brackets (2)
RP1010 Transformer
Literature kit
with gate
warning signs
Closed Position
Stop Plate
MMT103 Transmitter
A
F
G
I
E
B
C
H
D
8” Nylon Cable Tie (10)
J
3/8” Washer (9)
5/16” Clipped Washer (1)
K
L
3/8” x 8” Bolt (4)
M
3/8” x 1-1/2” Clevis Pin (2)
2” Mounting Screw (4)
S
R
3/8” Nut (7)
5/16” Lock Nut (1)
U
T
5/16” x 1-1/2” Bolt (1)
Q
W
P
3/8” x 2-3/4” Bolt (2)
®
3/8” Lock Washer (7)
V
3/8” x 1-1/2” Bolt (1)
Hairpin Clip (2)
#10-14 x 3/4” Screw (8)
N
O
ITEMS INCLUDED FOR GATE OPERATOR INSTALLATION (TS571W)
