Mighty Mule TS571W - Push-To-Open Operator Mounting

TS571W Installation Instructions 23
PUSH-TO-OPEN OPERATOR MOUNTING
G
V
T
O
L
G
11”
S
S
E
F
B
N
N
G
V
T
O
L
G
11”
S
S
E
F
B
N
N
Step 1
Step 2
● Assemble the gate post bracket subassembly
as shown with the Push-to-Open pivot bracket
(FM148). Must be purchased separate.
● Attach the gate post bracket subassembly and
gate bracket to the operator as shown.
● The operator must be fully retracted with the
gate in the desired open position.
Your Property
Push-to-Open pivot
bracket (FM148)
