41
Read Only (Function 0x03 or 0x04)
Register Description Type
Min.
Unit
Range
4080
Displacement Power
Factor L3
word 0.001 0 ~ 1.000
4081
Displacement PF
sign L3
word -
0=Resistive;
1=ind; 2=cap
4082 THD Current L1 word 0.1% 0 ~ 1000
4083 THD Current L2 word 0.1% 0 ~ 1000
4084 THD Current L3 word 0.1% 0 ~ 1000
4085 THD Voltage L1 word 0.1% 0 ~ 1000
4086 THD Voltage L2 word 0.1% 0 ~ 1000
4087 THD Voltage L3 word 0.1% 0 ~ 1000
4088 Energy Full Flag word
*Energy fl ag
bit 7 to 5 =
reserved
bit 4 = (-)kVARh
bit 3 = (-) kWh
bit 2 = kVAh
bit 1 = (+)kVARh
bit 0 = (+)kWh
4089 Power Factor L1 word 0.001 0 ~ 1.000
4090
Sign Power Factor
L1
word -
0=Resistive;
1=ind; 2=cap
4091 Power Factor L2 word 0.001 0 ~ 1.000
4092
Sign Power Factor
L2
word -
0=Resistive;
1=ind; 2=cap
4093 Power Factor L3 word 0.001 0 ~ 1.000
4094
Sign Power Factor
L3
word -
0=Resistive;
1=ind; 2=cap
*if the energy is full, the bit is set to 1, else bit is 0.
Table 7: Operation data register (cont)
