3-2. Miscellaneous Symbols And Definitions
. Some symbols are found only on CE products.
V
Voltage
On
Voltage Input
Protective Earth
(Ground)
Arc Force
X
Duty Cycle
%
Percent
Three Phase
Cold Jog (Inch)
Towards
Workpiece
Read Instructions
Program
Time
Alternating
Current (AC)
Remote
Negative
Variable
Inductance
Gas Metal Arc
Welding (GMAW)
U
2
Conventional
Load Voltage
I
2
Rated Welding
Current
Three Phase
Static Frequency
Converter-Transfo
rmer-Rectifier
A
Amperage
Off
Arc Force
Increase
U
0
Rated No Load
Voltage (OCV)
Hz
Hertz
U
1
Primary Voltage
IP
Degree Of
Protection
S
Suitable for Some
Hazardous
Locations
I
1eff
Maximum Effec-
tive Supply Cur-
rent
Constant Current
I
1
Primary Current
Wire Type
Trigger Hold On
Indicator Light
Output
Wire Feed
Trigger Hold Off
Sequence
Gas Type
Trigger Hold
Off Indicator Light
Cold Jog (Inch)
Away From
Workpiece
I
1max
Rated Maximum
Supply Current
Purge By Gas
Locked
Process
Arc Control
Direct Current
(DC)
Input
Positive
Constant Voltage
Line Connection
