3-2. Miscellaneous Symbols And Definitions
. Some symbols are found only on CE products.
Three Phase Static
Frequency
Converter-Trans-
former-Rectifier
1/
Single / Three
Phase Static
Frequency
Converter-Trans-
former-Rectifier
A
Amperes
V
Volts
I
1
Input Current
I
2
Maximum Effective
Supply Current
Gas Metal Arc
Welding (GMAW)
Percent
S
Suitable For
Welding In An
Environment With
Increased Risk Of
Electric Shock
Constant Voltage Power Connection
IP
Degree Of
Protection
X
Duty Cycle
I
1max
Rated Maximum
Supply Current
I
1eff
Maximum Effective
Supply Current
U
0
Rated No−Load
Voltage (Average)
U
1
Input Voltage
Direct Current
(DC)
Alternating
Current
(AC)
Protective Earth
(Ground)
Single Phase Three Phase
/
Single /
Three
Phase
