Miller Axcess E 300 - E Module Board Stack Diagnostic Leds

OM-244 814 Page 56
1 E Module Board Stack
Diagnostic LEDs are visible inside unit, lo-
cated on the E Module Board Stack.
Refer to Section 12-5 for information on
diagnostic LEDs.
Reinstall cover after checking diagnostic
LEDs.
250 237-A / Ref. 250 294-A
12-4. E Module Board Stack Diagnostic LEDs
1
D108
D101
D96
D1
D8
LED1LED2
D3
D4
D14
D10D11 D7
D103
D98
D92
D91
D99
