Milli-Q Millipore User Manual

Milli-Q® Reference System 17
Specifications and requirements
Milli-Q

Water
quality
The water delivered from a POD Unit has the following characteristics.
Parameter
Specification
Units
Resistivity
18.2
MΩ.cm @25°C
TOC
≤ 5
ppb
Particulates > 0.22 µm**
< 1
Particulates/mL
Bacteria**
< 0.1
cfu/mL
Pyrogens*
< 0.001
Eu/mL
RNases*
< 0.01
ng/mL
DNases*
< 4
pg/µL
Flow Rate**
0.05 – 2
L/min
(*) With BioPak

Final Filter
(**) With Millipak

or BioPak® Final Filter
NOTE:
These specifications are valid for Elix® water feed within specification and for routine
operation. Some specifications may not be achieved at start-up.
Weight
The various weights are found in the table below.
Item
Operating
Weight
Dry Weight
Shipping
Weight
Milli-Q® Reference
System
19.5 kg
14.5 kg
19 kg
Electrical
The electrical specifications and data are found in the table below.
Parameter
Value
Voltage
100-230 VAC ±10%
Frequency
50-60 Hz ±10%
Main Fuse
3.15 Amp Fast Acting; 5 mm x 20 mm;
250 V safety voltage.
The fuse should be serviced by a qualified Millipore
SAS Service Representative.
Power Used
125 VA
Power Cord Length
2.5 metres
Electrical Ground
Earth Grounded
Power Cord use
The System is powered on and off by removing the
power cord from the wall outlet.
The power cord should be plugged into a wall outlet
that is accessible.
Continued on next page

Milli-Q Millipore Specifications

General

Type of Water Produced	Ultrapure Water
Resistivity	18.2 MΩ·cm
Total Organic Carbon (TOC)	<5 ppb
Technology	Reverse Osmosis, Ion Exchange, Ultrafiltration
Particle Removal	Yes, through filtration
Storage Capacity	Varies by model
Display	Touchscreen display for system monitoring and control
Dimensions	Varies by model
Weight	Varies by model
Power Supply	100-240 V AC, 50-60 Hz
Bacteria Removal	Yes, through filtration and UV oxidation (depending on the specific Milli-Q system)
