Functions which can be assigned to the
digital control inputs via the Millimar:
Via the "SETTING" -> "I/O" -> "INPUT (4.7.1)"
item of the catalog of functions and param-
eters, Millimar functions can be assigned to one
of the digital inputs.
For each function select the number of the
input via which the corresponding function is
to be triggered. Entering the input number "0"
means that this function will not be triggered
via any of the inputs.
Each function can be assigned to just one of
the inputs whereas each of the inputs can be
assigned several functions. If several functions
are assigned to one input, the functions are
triggered according to an internally specified
sequence.
The following are possible functions:
START Start signal for measurement-
STOP Stop signal for measurement-
MEASURE Measurement period
CLRMXMN Reset signal for deleting the
Max, Min and average
memories
TXVALUE Signal for transmitting the
measuring value via the
RS-232 interface.
MAST EN OK signal for the master
measurement assigned to a
second input.The MASTER
function can either be assigned
to the same input as the
MAST EN function or to a
different (2nd) one.
MASTER Start signal for master
measurement
M1SEL Displays feature 1
(if "Autodetect" is on).
M2SEL Displays feature 2
(if "Autodetect" is on).
CLRSTO Deletes all values in the
measuring value memories.
SENDSTO Transmits all values out of the
measuring value memories.
