10 Setting parameters for recor ding
measured values .................................. 46
10.1 Setting filter parameters............................46
10.2 Specifying the measuring sequence ..48
10.3 Operating mode “NORMAL“ .................50
10.4 Operating mode “AUTOM.“ .................50
10.5 Entering a start delay ....................................51
11 Password protection ............................52
12 Performing measurements ...............53
12.1 Performing an aggregate measure-
ment ........................................................................54
12.2 Performing a differential
measurement .................................................... 54
12.3 Performing a radial run-out measure-
ment ........................................................................55
13 Measured value memories ................ 56
14 Using the serial interface (RS 232) .58
14.1 Selecting the interface protocol ...........58
14.2 Selecting the data transfer format ..... 60
14.3 Selecting the handshake .............................61
14.4 Selecting the transfer rate ........................ 62
14.5 Selecting how to initiate data transfer 63
14.6 Examples of interface configuration .64
14.6.1 Interface configuration for
data transfer to a printer .........64
14.6.2 Interface configuration for data
transfer to a computer ..............64
M1240 interface protocol ......................... 65
OPTORSD interface protocol .................. 67
OPTORSS interface protocol ...................68
MARTALK interface protocol .................68
14.7 Connecting to a PC using a zero-
modem cable (circuit diagram ) ............ 69
