Page 138 Accumass BW500 PL-565
Appendices
Error Codes
Error
Code
Code Name Message/Action
200 No Speed No speed registered during calibration. Check
conveyor running or speed signal.
201 Error – Load Cell A & B Reading between A & B > 20000, or no signal.
Check wiring.
202 Error – Load Cell C & D Reading between C & D > 20000, or no signal.
Check wiring.
203 Err: 203 Memory failure test. Consult Milltronics.
204 Integrator not configured P002-P017 must be programmed
205 Err: 205 Zero or span calibration required.
210 Remote Totalizer 1 exceeded Increase resolution.
211 Remote Totalizer 2 exceeded Increase resolution.
212 Maximum speed exceeded Speed is > twice the design speed. Check
design belt speed, actual belt speed, speed
constant. Perform speed constant adjust
(P018) if necessary.
213 Maximum rate exceeded Rate is > thrice the design rate. If no
mechanical cause, check to see if re-rating the
design rate is required.
220 Span Too Low Span is < 1 mV. Insure proper test weight or
chain is applied during span.
221 Span out of range Span deviation > 12.5%. Consider an initial
zero (P377). Refer to Initial Zero on page 46.
222 Zero out of range Zero deviation > minimum limit. Consider an
initial Span (P388). Refer to Initial Span on
page 49.
223 Security Violation An attempt to run command / calibration that is
not allowed under current security level.
224 Function not permitted Function not allowed under current security
level.
225 BF Flashes in the bottom right corner of display
when battery charge is too low.
226 Load Cell AD’s are not functioning Consult Milltronics.
227 Err: 227 No process data available. Consult Milltronics.
228 Batch pre-act adjustment > 10% Pre-act adjustment is ignored. Tune process to
limit batch error.
240 Integrator not configured P002-P017 must be programmed
241 No PID mA Input PID Process Value Source (P402) or PID
Setpoint (P414) has been programmed for a
mA Input, however mA Input Function (P255)
has not been programmed properly.
242 No PID mA Output PID System (P400) has been turned on, but
mA Output (P201) has not been programmed
properly.
243 No batch setpoint relay Batch has been setup, but no relay has been
configured for a setpoint.
