Page 18 Accumass BW500 PL-565
Installation
Scale – One Load Cell
*Where separation between the BW500 and belt scale exceeds 150 m (500 ft), or legal for trade
certification:
• remove the jumpers BW500 terminal 11/12 and 13/14
• run additional conductors from :
BW500 terminal 12 to scale `red'
BW500 terminal 13 to scale `blk'
• If load cell wiring colours vary from those shown, or if extra wires are provided,
consult Milltronics.
customer
junction box
*
Milltronics
Belt Scale
load cell
r
e
d
b
l
k
w
h
t
s
h
l
d
g
r
n
To Next Page
