Page 58 Accumass BW500 PL-565
Parameters
Start Up (P001 to P017)
This is the minimum parameter programming required before attempting a calibration
and successful entry into the run mode.
P001 Language
Selects the language for communication with the BW500
entry:
1 = english
f
Note:
This manual only lists English as a choice of language. However, your BW500 will
list the additional languages of choice, as the translated software is made
available.
P002 Test Reference Selection
Selects the type of test reference used to represent a material load: weight, chain or
electronic.
weight: the weight that is supplied specific to the scale
chain: optional, sized specific to scale and conveyor
electronic: calibration based on automatic calculation of the mV span from the load
cells
Entry:
1 = weight
f
2 = chain
3 = ECal
P003 Number of Load Cells
Milltronics belt scales are available in models of one, two or four load cell design.
Select the number of load cells corresponding to the belt scale connected.
If using the optional remote LVDT conditioner card, for LVDT based scales, select the
“1” value.
Entry:
enter the number of load cells: 1, 2
f
or 4
P004 Rate Measurement System
Selects system of measurement used, either imperial or metric.
Entry:
1 = imperial
2 = metric
f
