PL-565 Accumass BW500 Page 97
PID Control
Setpoint Controller – Master/Slave Control
*P201-03 = 1 also applicable
belt scale
speed
sensor
speed
load
SLAVE
speed
MASTER
control output rate
(P201-02=4)
remote ratio
setpoint rate
(P255-01 = 1
P418-01 to suit)
control
output
(P201-02=4)
rate*
(P201-01 = 1)
remote setpoint rate
(P255-01 = 1)
load
speed
sensor
PID 1 process value source -rate
(P402-01 = 1)
PID 1 process value source -load
(P402-01 = 1)
motor
speed
controller
motor
speed
controller
