7-6 Adjustments
7.3 Caster Adjustment
There are four braking casters of the main unit, as shown in the figure: tread the 2 “On” button
downwards by foot to lock the caster, tread the 1 “Off” button downwards by foot to release the
caster. When locking or releasing the casters, move the casters if necessary.
RELEASING LOCKING
OFF
ON
1 2
