Structure and Assembly/Disassembly 9-1
9 Structure and
Assembly/Disassembly
9.1 Structure of the Entire System
No. Name No. Name
<1>. Touchscreen assembly <2>.
Right side-panel assembly of main unit
<3>. Top cover assembly of the control panel <4>.
Keyboard assembly
<5>.
Printer cover
<6>.
Rear cover assembly of main unit
<7>. Cast-aluminum base <8>.
Main body and keyboard assembly
<9>. Speaker assembly
<10>
Left side-panel assembly of main unit
