Field Replaceable Unit 8-19
No. Order Number Part Name Qty. Remark
E12-1 115-051521-00 IO Board Assembly(FRU) 1
E12-2
115-051210-00 WIFI Module Kit(EWM-W163M201E) 1
Including Wi-Fi card and the Wi-Fi antenna.
For upgrade use
023-001528-00 Wi-Fi module Wi-Fi + BT 1 Only Wi-Fi card. For repair.
E12-3 024-000965-00 M.2 port wifi antenna 1 Including one Wi-Fi antenna
E12-3
E12-2
E12-1
