Mindray DC-70 Pro User Manual

Structure and Assembly/Disassembly 9-3
 Sketch
Left side panel
DC module
TR
board
Front cover
Control panel
assembly
TGC
Board
Trackball
assembly
Buzzer
Display
assembly
Air intake
fan
Engine
board
4D
board
Encoder
board
Top
cover
assembly
LCD
control
panel
Adjus
tment
keys
Front
cover
Rear
cover
Note:
1. The ordinate implies the disassembly orders.
2. Each square on the top implies an
independent disassembly.
ECG
assembly
Probe board
assembly
Lithium
-ion
battery
Rear cover
WIFI
board
IO
board
Power
supply
input
assembly
Hard
disk
PC module
Digital
board
Air offtake
fan
Right side
panel
Mother board
Speaker
Mac
hine
asse
mbly
NOTE: The illustration of disassembly is for reference only; please relies on the actual model.

Mindray DC-70 Pro Specifications

General

Touch Screen	Yes
Touch Panel	Yes
Transducer Ports	4
Battery Backup	Yes
3D/4D Imaging	Yes
Operating System	Windows-based
Power Supply	100-240V AC, 50/60 Hz
Storage	500GB HDD
Connectivity	USB, HDMI
Applications	Cardiology, Obstetrics, Gynecology
Imaging Modes	Color Doppler, Power Doppler
Ports	USB, Ethernet, HDMI
Display Size	19 inch
