Mindray DC-70 Pro User Manual

2-6 Specifications
2.1.2.4 Control Panel
No. Name Description
<1> /
Power button
Press the button to turn on the system, the system enters the work
status and the indicator becomes green.
<2> Volume Adjust the volume.
<3> /
Adjust the corresponding functions on the touch screen.
<4> /
<5> /
<6>
/
<7> /
<8> TGC Slide to adjust the depth gain.
<9> Patient Enter/exit Patient Info screen.
<10> Probe Switch probe and exam mode.
<11> Review Review the stored images.
<12> Report Open/close the exam report.

Mindray DC-70 Pro Specifications

General

Touch Screen	Yes
Touch Panel	Yes
Transducer Ports	4
Battery Backup	Yes
3D/4D Imaging	Yes
Operating System	Windows-based
Power Supply	100-240V AC, 50/60 Hz
Storage	500GB HDD
Connectivity	USB, HDMI
Applications	Cardiology, Obstetrics, Gynecology
Imaging Modes	Color Doppler, Power Doppler
Ports	USB, Ethernet, HDMI
Display Size	19 inch
