Mindray DC-70 Service Manual

Specifications 2-5
2.1.2.3 Physio Panel
No.
Name
Function
<1> USB port Connects USB device.
<2> Pencil probe port Used for connecting a pencil probe.
<3> MIC port Used for connecting a microphone.
<4>
ECG lead signal input
port/external ECG
signal input port
Connects to ECG leads to directly obtain the patient's ECG
signals.
Connects the signal output port of an external ECG monitoring
device.
<5> PCG signal input port Reserved.
<6> Reserved port Reserved.

Mindray DC-70 Specifications

General

Power Supply	100-240V AC, 50/60Hz
Imaging Modes	B-mode, M-mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Probes	Convex, Linear, Phased Array, Volume
Connectivity	USB, Ethernet, VGA
Advanced Features	3D/4D Imaging
Applications	Abdominal, Obstetrics, Gynecology, Cardiac, Small Parts, Vascular, Musculoskeletal, Urology
Weight	Approx. 85 kg
Operating System	Windows-based
