Mindray DC-70 Service Manual

2-6 Specifications
2.1.2.4 Control Panel
No. Name Description
<1> /
Power button
Press the button to turn on the system, the system enters the work
status and the indicator becomes green.
<2> Volume Adjust the volume.
<3> /
Adjust the corresponding functions on the touch screen.
<4> /
<5> /
<6>
/
<7> /
<8> TGC Slide to adjust the depth gain.
<9> Patient Enter/exit Patient Info screen.
<10> Probe Switch probe and exam mode.
<11> Review Review the stored images.
<12> Report Open/close the exam report.

Mindray DC-70 Specifications

General

Power Supply	100-240V AC, 50/60Hz
Imaging Modes	B-mode, M-mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Probes	Convex, Linear, Phased Array, Volume
Connectivity	USB, Ethernet, VGA
Advanced Features	3D/4D Imaging
Applications	Abdominal, Obstetrics, Gynecology, Cardiac, Small Parts, Vascular, Musculoskeletal, Urology
Weight	Approx. 85 kg
Operating System	Windows-based
