Mindray M8

To Next Page

To Previous Page

Field Replaceable Unit 7-15

7.2.6 UMT-500 Mobile Trolley (F0)

No.

Order Number

Part Name

Qty.

Remark

F1 115-021103-00 USB-HUB assembly 1

F2 051-001386-02 Cart AC Connector Board 1

F3 051-001387-02 Cart Battery Control Board 1

F4 022-000148-00 Power Supply Board 1

F11

F10

F12

F13

F14

F17

Main Page
