Structure and Assembly/Disassembly 8-33

8.3.4 Trolley Panel Board Assembly

1. Unscrew 10 screws (M4 X 12 cross panhead screw) on the back of trolley panel’s base, and

take out the panel cover.

2. Remove the rotatable clasp

Unscrew 2 screws on the fixing bracket for the spring (M4 X 12 cross panhead screws), and

take out the fixing bracket and the spring.

M4X16 cross panhead with the pad and the clip (4 screws)

M4X12 cross panhead screw

(10 screws)
