8-
32
S
truc
ture and Assembly/
Disassembly
Unscrew 4 screws
(M4 X 8 cross panhead screw) on the bac
k of
AC
-
DC supporting boa
rd, and
take out
AC
-
DC power supply board.
6.
Unscrew 4 screws
on the power supply fan (M4 X
16 cross panhead with the pad and the clip).
T
ake out the fan.
M3X6 cross panhead screw (4 screws)
M4X8 cross panhead screw (4 screws)
161
163
