Structure and Assembly/Disassembly 8-27
8.3 Trolley Assembly/Disassembly
8.3.1 Preparation
8.3.1.1 Disassembly Tools Required
Name
Type
Material No.
Remarks
Cross-headed
screwdriver
107*75 / M2
Cross-headed
screwdriver
102*100 0000-10-10884
M3、M4
Inner hexagon
spanner
369H(1.5-6.0mm)
095-000062-
M5
Spanner 1PK-H024 095-000063-00 4″
Diagonal cutting
pliers
N-206S
095-000077-
/
Anti-electrostatic
glove: 1 pair.
/ / /
8.3.1.2 Engineers Required
The disassembly should be performed by professionals from Mindray or the staff who are trained to
be qualified for the maintenance.
to magnet
M2.5X4 cross panhead screw, 4
screws; 2 screws for each left and
right side
To Next Page
