System Diagnosis and Support 10-11
*** [CCC]([HH]).[XXX] supply voltage error. [XXX] volt is
[PPP] V (upper limit is [LLL]V).
in which [CCC] refers to the frame name of current
alarming protocol and [HH] refers to frame header.
[XXX] refers to the name of high voltage, such as: PHV-1P,
PHV-1N, PHV-2P, PHV-2N, CW-P and CW-N.
[PPP] refers to absolute value of current voltage.
[LLL] refers to upper limit of preset voltage.
Restart the device to
check whether the
system can work again.
Otherwise, it is
necessary to cut off the
power supply after
shutting down the
device.
If the problem
still exists, replace front
power supply board.
*** [CCC]([HH]).[XXX] supply voltage error. Current volt is
[PPP] V, out of range 95V~105V.
in which [CCC] refers to the frame name of current
alarming protocol and [HH] refers to frame header.
[XXX] refers to the name of high voltage, the range of
which is from +100 V to -100 V.
[PPP] refers to absolute value of current voltage.
*** PHVCURRENT_WAR（0xB2）.Channel [XXX] supply
current error. Channel [XXX] current is [PPP]mA.
[XXX] refers to channel number of voltage: 0-3.
[PPP] refers to current value of current voltage channel.
*** [CCC]([HH]).PHV volt abnormal protection. {PHV-1P
volt:[PPP]V, PHV-1N volt: [PPP]V,} PHV-2P volt: [PPP]V,
PHV-2N volt: [PPP]V.
in which [CCC] refers to frame name of current alarming
protocol and [HH] refers to frame header of protocol.
[PPP] refers to absolute value of current voltage.
{..} indicates that PHV-1P and PHV-1N voltage are not
used (such as CW-Multiplex mode). It can be ignored.
Cut off the power supply
after shutting down the
device. Then, restart the
device. Check the
restoration of the
system. Otherwise, it is
necessary to replace
PHV power supply
board.
*** [CCC]([HH]).CW volt abnormal protection. CW-P volt:
[PPP]V, CW-N volt: [PPP]V.
in which [CCC] refers to frame name of current alarming
protocol and [HH] refers to frame header of protocol.
[PPP] refers to absolute value of current voltage.
10.3.6 Other Errors
10.4 Self-test
10.4.1 Self-test Introduction
The self-test function, adopted by M9 series products, is used to test the connection of hardware
board, running status of the device. According to the access authority and tests, there are three
Alarming tips
LOG record
Suggestion
Fail to open the file "SystemConfiguration.ini",
and please check HDD data!
N/A
Re-install the system
software.
