S
truc
ture
and Ass
embly/Disassembl
y
8-9
3.
Open control panel. Extrac
t the signal cables of
control panel, and remove the control
panel.
4.
Unscrew 4 screws
(M3 X 8 Nylok screws) as
shown in the Figure. Rem
ove the monitor
upward
s.
Extract signal cables of cont
rol panel
M3X8 Nylok screw (1
1 screws)
138
140
