S
truc
ture
and Ass
embly/Disassembl
y
8-
11
4.
Unscrew 2 screws
on ECG fixing bracket
(M3 X 8 Nylok screw).Remove EC
G's fixi
ng bracket
and extract ECG connec
ting cables.
5.
Remove the speaker as
sembly
. Unplug the sock
et on the main board.
M3 X 8 Nylok screw (2 screws)
ECG fixing bracket
ECG connecting board
Connecting cables to
ECG socket
Pressure plate
M2 X 4 stainless steel cross head screw (4 screws)
ECG signal
cables
140
142
