System Installation 3-31
3) Click [Add] to add the server to the list if the connection works normally.
The following is an example:
Note:
1. AE Title should be the same with the SCU AE Title preset in the server
(PACS/RIS/HIS).
2. DICOM communication port should be the same with the one on the server.
If the currently entered name has already existed, the system will pop up:
“The server name exists!”
3. Click [DICOM Service].
When the system is configured with DICOM basic function module, and installed DICOM Worklist,
storage commitment, and Query/ Retrieve modules, the corresponding preset settings can be found
in DICOM Service screen.
