Mindray TE7 User Manual

DICOM/HL7 11-1
11 DICOM/HL7
NOTE:
Before using DICOM, read the DICOM CONFORMANCE STATEMENT electronic
file provided with the device.
The chapter is restricted to the preset, connection verification and DICOM services of the DICOM-
configured ultrasound machine, and does not include SCP configurations such as PACS/RIS/HIS.
The DICOM package is optional. For details, see “2.3.3 Options”.
This system supports the following DICOM functions:
 Verify Connectivity
 DICOM Storage
 DICOM Print
 DICOM Worklist
 MPPS (Modality Performed Procedure Step)
 Storage Commitment
 Query/Retrieve
 Structured Report
 DICOM Medium Storage (DICOMDIR Review)
 DICOM Task Management
DICOM Preset and Applications workflows are briefly described as follows:
1. DICOM preset (network property, DICOM local preset, server and service preset).
2. Verify connectivity (tap [Verify] in corresponding screen).
3. Services application.
4. DICOM task management.
 Terms
Abbreviations
Description
DICOM
Digital Imaging and Communications in Medicine
AE
Application Entity
MPPS
Modality Performed Procedure Step
PDU
Protocol Data Unit
SCU
Service Class User (DICOM client)
SCP
Service Class Provider (DICOM server)
SOP
Service-Object Pair
TLS
Transport Layer Security

Mindray TE7 Specifications

General

Display Size	15 inch
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Tissue Doppler
Connectivity	USB, HDMI, DICOM, Wi-Fi
Probe Connectors	3
Image Storage	External USB storage
