5-28 Image Optimization
Dual Live
In live mode or freeze mode, tap [Dual Live] to enable the dual live function. Both the contrast
image (marked with “ ”) and the tissue image (marked with “ ”) are displayed (the position can
be changed).
Tips:
In dual live mode, the screen displays the contrast image and tissue image
In freeze mode, only one cine review progress bar displays as the contrast image and
tissue image are reviewed synchronously.
Image position
Use [CEUSPos: XX] to adjust the position of the contrast image.
When it is selected as “Left”, the image displays at the left part of the image area on the screen.
Mix Map
This function combines the contrast image with the tissue image, so that the contrast regions of
interest can be located.
Select options besides [Mix] to select different mixing modes: Contrast and C&T.
When the dual live function is on, you can see the mixed effect on the contrast image.
When the dual live function is off, you can see the mixed effect on the full-screen image.
iTouch
In contrast status, you can also get a better image effect by using the iTouch function.
Tap to turn the function on (the icon turns blue).
Long press to exit the function.
Image Saving
Live capture
In live mode, you can save the images of interest by tapping [Pro Capture] and [Retro Capture].
Cine saving
In freeze mode, tap [Save Clip] at the bottom of the operating panel.
