Mindray TE7 User Manual

Image Optimization 5-35
5.9.2 TDI Image Parameters
 In TDI mode scanning, the image parameter area in the top-left corner of the screen will
display the real-time parameter values as follows:
 TVI/ TEI
Display
F
G
PRF
WF
Parameter
Frequency
Gain
PRF
WF (Wall Filter)
 TVD
Display
F
G
PRF
WF
SVD
SV
Parameter
Frequency
Gain
PRF
WF (Wall Filter)
SV Position
SV Size
 TVM
Image parameters combine the parameters of TVI mode and M mode.
5.9.3 TDI Image Optimization
 In TVM mode, adjustable parameters are the same as those in B, M, and TVI modes; please
refer to the relevant contents for details.
 In each TDI mode, parameters that can be adjusted are similar to those in the color flow
modes (Color, PW, and Power); please refer to relevant chapters for details. The following is to
introduce the specific items in TDI mode.
Tissue State
Description
This function is used for a fast image optimization by providing an adjustment on
2 parameters, including scale and filter.
Operation
Adjust through the [Tissue State] item in the menu.
There are 3 levels provided to adjust: L, M, H.

Mindray TE7 Specifications

General

Display Size	15 inch
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler, Pulsed Wave Doppler, Tissue Doppler
Connectivity	USB, HDMI, DICOM, Wi-Fi
Probe Connectors	3
Image Storage	External USB storage
